Yes, boxing in a soil pipe is a common and straightforward way to hide it and cut down on noise. But there are three things worth getting right that go beyond just covering it with plywood: ventilation, access, and (on older properties) checking what the pipe itself is made of before you start.
What boxing in a soil pipe actually involves
The step-by-step process using plywood
Why the box needs to breathe, not just look neat
Why you shouldn't seal over joints and valves permanently
What to check before touching an older soil pipe
When to bring in a plumber instead of DIY
Find a plumber near me
What is boxing in a soil pipe?
Boxing in a soil pipe means covering it, usually with plywood or MDF, to hide it and reduce the noise it makes as waste water moves through. Soil pipes (also called soil vent pipes) carry waste water from your toilet, sink, bath, or shower to the underground drainage system. Many modern homes route this pipe outside the building, but there will always be a stretch of it inside the bathroom itself, and some older properties still run the full stack indoors.
Boxing doesn't need to seal against the pipe. Leaving a small gap, using spacer blocks between the pipe and the boxing, actually helps: it reduces noise and heat transfer, and avoids the boxing cracking or warping over time.
Boxing in a soil pipe using plywood
Attach a piece of timber to the wall, parallel to and just above the soil pipe.
Attach another piece of timber to the floor below the pipe, positioned at the width you want the finished box to be.
Measure the distance from wall to floor timber, and from floor to the top of the wall timber, along with the length you want the box to run.
Cut two pieces of plywood to size: one for the front of the box, one for the top.
Screw the front piece to the floor timber.
Fix the top piece to the wall timber.
Finish the box by tiling or painting it to match the surrounding walls and floor, if you'd like it fully blended in.
To reduce noise further, line the inside of the box or wrap the pipe itself in mineral fibre insulation before closing it up.
Why the box needs to breathe
This is the step that gets skipped most often, and it's the one that causes problems later. Soil stacks need to vent properly, often right up above roof level, and fully sealing a stack inside tight, airtight boxing can trap moisture, leading to condensation forming inside the box that eventually soaks into the surrounding wall or floor.
Standard guidance for boxed-in soil pipework calls for a ventilation area of at least 2500mm² (unless the pipe's manufacturer specifies otherwise), achieved through:
Small grille vents on the face of the boxing, or
A discreet gap left at the top or bottom of the box (even a 5-10mm gap can be enough), or
Venting the boxing into a ventilated roof void, where the stack runs up through the loft
In a full-height enclosure, aim for ventilation near both the top and bottom of the box, not just one end, to keep air actually moving through rather than sitting stagnant.
If the pipe you're boxing in is already leaking or showing signs of a fault, sort that first. Our guide to diagnosing and fixing a leaking soil pipe covers the common causes.
Don't seal over joints, traps, or valves
Any isolation valves, traps, or pipe joints inside the boxing may need maintenance access at some point, and a common mistake is boxing tightly around them with fully fixed, glued panels, only to have to break the whole thing open later when something needs attention.
Building an access panel into the design from the start, rather than a single continuous fixed front, saves that hassle. Standard access panel sizes (roughly 150mm x 150mm up to 300mm x 300mm) are widely available and can be positioned directly over the section you're most likely to need to reach again.
On Checkatrade, you'll only find trades who meet our high standards and pass up to 12 checks.
Before boxing in an older soil pipe, check what it's made of
If your property was built or plumbed before around 2000 and the soil pipe is old cast iron rather than modern plastic, don't start cutting into or disturbing any lagging or boarding around it before checking for asbestos. Older cast iron soil pipes were sometimes fitted with asbestos-containing lagging or boards, and disturbing this without checking first is a genuine health risk. Our guide on safely removing an asbestos soil pipe covers what to do if you suspect this applies to your property.
Boxing in a soil pipe in an extension
If you're building an extension or doing other major construction work and need to deal with an exposed soil pipe, you have two main options:
Box it in, following the same approach described above, or
Bring the whole wall out slightly using plasterboard, so the pipework sits behind a flush wall surface rather than a visible boxed-in section
The second option costs a little more but avoids an obvious jutting box interrupting the wall line, which can be worth it in a room where appearance matters more.
How Much Does a New Bathroom Cost in the UK?
Planning to build a new bathroom? We've put together a list of the most common costs for a new bathroom to help you plan your budget.
Before you box in a soil pipe
Frequently asked questions
For a straightforward domestic boxing job, no formal permission is usually needed, though ventilation and access requirements still apply. In shared buildings like flats, fire-stopping between units can also be relevant, so check if that applies to your property.
No, this is one of the most common mistakes. Soil stacks need ventilation to prevent condensation building up inside the boxing, which can otherwise soak into nearby walls or floors over time.
Yes. Any valves, traps, or joints that might need future maintenance should stay reachable, ideally through a dedicated access panel rather than a fully fixed, glued-shut front.
Check for asbestos first if the property or pipework predates around 2000. Disturbing asbestos-containing lagging or boards without checking is a genuine health risk, and this is worth confirming before any DIY work begins.
Yes, lining the box or wrapping the pipe in mineral fibre insulation before closing it up noticeably reduces the noise of waste water moving through.
DIY boxing with plywood is inexpensive if you're comfortable with basic carpentry. A plumber becomes worthwhile if you're unsure about ventilation, access requirements, or suspect the pipe may be older cast iron with asbestos-containing materials.
